Rinsing Filling & Capping Machine for Hot / Cold Juice
Automatic Rinsing, Filling Capping (Hot Fill) Juice Filling Machine
This Filling Line includes 12 Head Auto Washing System, 12 Head Auto Filling System with 12 Special purpose Filling Valve TO Fill HOT Juice at 72 degree Temp. &4 Head Capping Unit which are connected by Motor driven Air Conveyor system provided in line for Filling Juice (HOT FILL) into PET Bottles up to 2000 ml. The production capacities of this line reach 3600 – 4500 bottles/hour at 1000 ml. (if provided with good quality PET Bottles and CAP).
FEATURES
Automatic Juice Filling Machine Manufacturer in Mumbai
Beautiful Outlook & Sturdy Design, Easy operation, Compact Size & Convenient maintenance
The Machine is Rotary in Design with Rinsing, Filling & Capping in one unit for all kind of Liquid Filling
Contact parts are made of high grade Stainless Steel with compact Electrical Panel with reputed brand provided
The machine has No Bottle No Rinsing, No Filling & No Capping Auto System.
No Timer, No Sensor system provided. It is Fully Mechanically operated Machine
Special design of Filling Valve gives accurate Filling and Speed
Provided with compact Cap Feeder for Capping with Pick & Place system for Capping with Torque Capping
This machine is also suitable for Hot Filling, Juice Filling & Oil Filling provided by changing few Machine parts.
MAIN TECHNICAL SPECIFICATIONS
Automatic Juice Filling Machine Manufacturer in Mumbai
Production Capacity : 3600 bottles/hour (at 1000 ml)
Washing Head : 12
Filling Head : 12
Capping Head : 4
Filling Accuracy : ± 2 %
Compressed Air : 2 CFM
Power Consumption : ≤ 5 hp
Gross Weight (kg) : 3000
Dimensions (LxWxH) (mm) : 2300 x 2000 x 2400
