Cooling / Warmer Tunnel for Juice Line
Semi Automatic Cooling Tunnel Machine for Juice (Hot Fill)
Semi automatic Cooling machine Manufacturer in Mumbai, The machine is used for cooling HOT filled PET bottle for a time period with cold Water spray to decrease the temperature of the PET bottle which helps the bottle to remain in its Original shape.
DETAILS SPECIFICATIONS ARE BELOW
COOLING TUNNEL DIMENSION : 900 MM X 20 FEET LONG
POWER SUPPLY : 220V OUTPUT
MACHINE OUTPUT : ADJUSTABLE SPEED
INFEED CONVEYOR : 10 FT SS SLAT BELT CONVEYOR
PNEMATICS PARTS : CYLINDER 50 X 250 FOR PUSHING BOTTLE IN THE TUNNEL
TUNNEL SPECIFICATION : MULTI NOZZLE WITH PUMP PRESSURE LINE
CONTROL PANEL : IN THIS PANEL ALL CONTACTORS ARE TELEMACHINC MAKE DELTA AC DRIVE
TUNNEL MATERIAL : FULLY STAINLESS STEEL 304 GRADE MATERIAL
AIR CONSUPMTION : AIR PRESSURE 2KG/ 3CFM
TUNNEL CONVEYOR BELT : DERLIN MAKE
MOTOR : MATRIX 1 HP, 3 PHASE AC MOTOR
TUNNEL OPENING : 900MM ( W) X 750MM (H )
TOTAL DIAMENTION : 6100 MM (L) X 980 MM (W) X 1720 MM (H)
COOLING ZONE : COOLING FAN PROVIDED FOR FAST COOLING
